Keep Your Jeep Wrangler JK Running Forever Proper maintenance is the key to preventing expensive repairs and keeping your 2007-2018 Jeep Wrangler JK reliable both on the road and on the trail. Whether you are running the early 3.8L V6 or the newer 3.6L Pentastar engine, strictly following the factory service intervals is critical.
Missing oil changes, differential fluid swaps, or vital suspension inspections can quickly lead to bigger problems like Death Wobble or engine failure. Use our interactive Jeep JK Maintenance Schedule Tool below to stay ahead. Simply select your current mileage or timeframe, and instantly get a comprehensive checklist of what needs to be inspected, replaced, or serviced right now.
Jeep Wrangler JK Maintenance Schedule & Service Intervals
The definitive factory service manual (FSM) guide for maintaining your 2007-2018 Jeep Wrangler. Complete fluid capacities, torque specs, and interactive mileage-based scheduling.
JK Fluid Capacities & Specifications (3.8L vs 3.6L)
Using the correct fluid type and volume is critical. Below are the definitive factory specifications for both the early EGH 3.8L V6 and the newer Pentastar 3.6L engines.
| Component | 2007-2011 (3.8L V6) | 2012-2018 (3.6L V6) |
|---|---|---|
| Engine Oil | 6.0 Quarts (5W-20) | 6.0 Quarts (5W-20) *2013+ may use 5W-20 or 0W-20 |
| Engine Coolant | 13.4 Quarts (HOAT – Orange) | 10.5 Quarts (OAT – Purple/Pink) DO NOT MIX HOAT AND OAT! |
| Automatic Transmission | 42RLE (4-Spd): ATF+4 | W5A580 (5-Spd): ATF+4 |
| Manual Transmission (NSG370) | 1.59 Quarts (Mopar Manual Trans Fluid or Synchromesh) | |
| Transfer Case (NV241) | 2.0 Quarts / 4.2 Pints (ATF+4 Only) | |
| Front Axle (Dana 30/44) | 1.35 Quarts / 2.7 Pints (80W-90) | |
| Rear Axle (Dana 44) | 2.37 Quarts / 4.75 Pints (75W-140 for Towing/Severe) *Add Friction Modifier if equipped with Trac-Lok LSD |
|
Interactive Service Scheduler
Generate a custom factory-recommended maintenance list based on your specific JK setup.
Service Action Plan: Miles
The “Death Wobble” Prevention Protocol
Routine fluid changes are not enough for a solid front-axle vehicle like the JK. To prevent the infamous “Death Wobble”, every 10,000 miles you must inspect the following components for play or worn bushings:
- Front Track Bar: Check both the frame-side bracket bolt (125 ft-lbs) and the axle-side bolt (125 ft-lbs).
- Tie Rod Ends & Drag Link: Inspect grease boots for tearing and check for vertical/horizontal play.
- Ball Joints: Jack up the front axle and use a pry bar under the tire to check for vertical movement. Factory plastic-lined ball joints typically fail between 40k-60k miles.
Need exact torque specs for your suspension? Visit our Master JK Torque Specification Database.
